- product name:LSK 05-05
- category:thyssenkrupp
- Brand:thyssenkrupp
- manufacturer:thyssenkrupp
- use:Laser welding
- major client:
- description
- features
- parameter
- Case
One tool, many capabilities
How to achieve vehicle weight reduction? How to improve the body strength? How to optimize the passive safety of vehicles? ——Laser welding provides an effective solution.
ThyssenKrupp has designed a compact and flexible body laser welding system-LSK05 series for well-known car companies such as German Volkswagen and Audi, which can not only meet the welding of aluminum alloy plates, but also meet the requirements of galvanized sheets and super Welding of strong steel body sheet metal.
LSK05-05 is a brand-new tool for unidirectional finger pressing developed by LSK05-01 as the basic function module. It adopts 90° right angle design and patent design unilateral finger pressing system, which presses the workpiece surface unilaterally. At the same time, laser welding (optional 1D scanning, optical welding seam tracking and other functions) can be applied to the roof, side sills, battery cover and other processes. At present, more than 30 sets have been delivered worldwide.
? 最大激光功率≤8kw（可定制最大20kw）
? 單壓指系統的壓力≤700N（可在線無級設定）
? 焊接速度快≤200mm/s
? 高效的光學鏡組，可有效降低激光能量損耗
? 采用螺旋噴嘴，有效延長護鏡使用壽命及減少壓縮空氣使用量
? 聚焦鏡下方安裝有兩塊護鏡，對聚焦鏡雙重保護
? 噴嘴上方設有便捷式護鏡抽屜模塊，并可實時監控護鏡污染狀態
? 獨特的一體化除塵模塊，可有效減少焊接過程中的飛濺和煙塵
? 定制的防護衣，可有效防護飛濺、粉塵等異物對設備的影響
? 采用總線通訊控制方式，可支持各種不同總線形式
? 產品一體化簡潔設計，易于現場快速安裝集成
? 可全面提供設備的備件、維修、技術支持及培訓等一站式售后服務
? 可選增1D掃描模塊及光學焊縫跟蹤功能，可應用于鋁合金角焊形式。
